Page 6-22 Document Ref 905675-001 Rev 2
Maintenance Modes WWC T1 Set Up & Maintenance Manual
Issue B
6.23.1 PRODUCT NAME BY CHARACTER INPUT
Display Explanations/comments
o U t 1 Product Name selection character by character.
-
The first - is flashing.
rIn1 Press 9 to scroll through the character list to select the first
character of the product name.
Press 8 to save and select next character.
o U t 1 The second - is flashing.
-
Press 9 to scroll through the character list to select the second
r I n 1 character of the product name.
Press 8 to save and move to next character.
Repeat process until all 6 digits have been selected.
Press 8 to save and continue.
oUt
1
The upper 1 (external product number) is flashing.
Press 9 to increase the value until the correct external product
r I n 1 number is reached.
Press 8 to save and continue.
oUt 1 The lower 1 (internal product number) is flashing.
Press 9 to select next internal product.
rIn
1
Repeat process until the product relations and product names
have been set for all configured internal product codes.
Press 9 to save and continue (when last product is displayed).
c o P Y Copy Right to Left menu.
r t o L This function enables the configuration settings for the right side
no
(side A) of the dispenser to be copied to the left side (side B).
Press 9 to toggle between yes and no.
Press 7 to save and continue.
To Next Page
