InstallingtheEngine(continued)

10.Secureenginecoolantreservoirandbrackettothefanshroudandradiator

frame(Figure55):

A.Positioncoolantreservoirandbrackettothefanshroud.Securebracket

tofanshroudandradiatorframewith2button-headscrewsandange

nuts.

B.Connectoverowhosetoradiatorllopeningandsecurewithhose

clamp.

11.Installaircleanerassembly;refertoAirCleanerAssembly(page3–8).

IMPORTANT

Wheninstallingtheexhaustsystem,ensuretousethefastener

tighteningorderidentiedinExhaustSystem(page3–11).

12.Installexhaustsystemtomachine;refertoExhaustSystem(page3–11).

Exhausttubeshouldhave9.5mm(3/8inch)clearancewithguardinall

directionsafterassembly.

13.Addenginecoolanttoradiator.

14.Checkenginehydraulic-uidlevelandadjustifnecessary.

15.Closehoodandconnectpositive(+)andthennegative(-)batterycablesto

thebattery.

16.Primethefuelsystem;refertoPrimingtheFuelSystem(page5–12).

17.Startengine.Checkforuidleaksandproperengineoperation.

18.Afterrunningengineforashorttime,stopengineandensureradiatorand

hydraulicreservoirarefull.Addcorrectuidsifnecessary.

19.Lowerandsecurehood.

20.Installandsecurescreentorearofmachine.

Reelmaster

5410/5510/5610Series

Page5–25

KubotaGasolineEngine:ServiceandRepairs

15216SLRevC
