ExhaustSystem

g229074

Figure14

Reelmaster5410/5510

1.Exhaustgasket8.Bolt15.Rubberhanger

2.Lockwasher(4each)

9.Isolatorplate

16.Spacer(2each)

3.Flangenut(4each)10.Hexnut(2each)

17.Exhaustheader

4.Bolt(4each)11.Clamp18.Supportbracket

5.Carriagescrew(4each)12.Flangenut(2each)

19.T ailpipebracket

6.Flangenut(4each)13.Flatwasher(2each)20.Mufer

7.Lockwasher

14.Bolt(2each)

Note:Reelmaster5010seriesmachineswithaKubotadieselenginehavevery

similarexhaustsystems.Reelmaster5410and5510machinesusethesame

exhaustsystem(Figure14).Reelmaster5610machinesuseaslightlydifferent

exhaustsystem(Figure15).

RemovingtheExhaustSystem

CAUTION

Themuferandexhaustpipemaybehot.Toavoidpossibleburns,

allowtheengineandexhaustsystemtocoolbeforeworkingonthe

exhaustsystem.

Reelmaster

5410/5510/5610Series

Page3–11

KubotaDieselEngine:ServiceandRepairs

15216SLRevC
