RemovingtheSteeringControlValve

1.Parkthemachineonalevelsurface,lowerthecuttingunits,shutoffthe

engine,settheparkingbrake,andremovethekeyfromthekeyswitch.

g185930

Figure185

1.Platformshroud3.Washer(2each)5.Coverplate7.Spacer(2each)

2.Washer-head

screw

(6each)

4.Screw(2each)6.Bushing(2each)8.Flangenut(2

each)

2.Removethefastenersthatsecuretheshroudtothefrontofthemachine

(Figure185).Removetheshroudfromthemachinetogetaccesstothe

steeringcontrolvalve.

3.Locateandretrievethe2rubberbushingsandspacers.

4.Slidetherubberbellowsupfromthebottomofthesteeringcolumn.

5.Supportthesteeringcolumntopreventitfromfalling.

6.Loosenandremovethe4ange-headscrewsand4angenutsthatsecure

thesteeringcolumnbrace(item12inFigure184)tothemachine,and

removethebrace.

7.ReadtheGeneralPrecautionsforRemovingandInstallingtheHydraulic

SystemComponents(page6–145).

Reelmaster

5410/5510/5610Series

Page6–223

HydraulicSystem:ServiceandRepairs

15216SLRevC
