TestingtheEngineSpeedSwitch(continued)
CircuitLogicTable
SwitchPositionNormalCircuitsOtherCircuits
DECREASE2+15+4
OFF
NoneNone
INCREASE2+35+6
Note:Theenginespeedswitchterminals4,5,and6arenotusedonthe
Reelmastermachines.
8.Replacetheenginespeedswitchiftestingdeterminesthattheswitchis
damaged.
9.Iftheenginespeedswitchtestingiscorrectandacircuitproblemstillexists,
checkthewireharness;refertotheElectricalSchematicandWireHarness
Drawings/DiagramsinAppendixA(pageA–1).
10.Afteryoucompletethetesting,connectthewireharnessconnectortothe
enginespeedswitch.
11.Securethecontrolarmcoverstothemachine;refertoAssemblingthe
ControlArm(page8–25).
Reelmaster
®
5410/5510/5610Series
Page7–69
ElectricalSystem:TestingtheElectricalComponents
15216SLRevC
