g229072

Figure12

Reelmaster5610

1.Aircleanerassembly7.Adapter13.Aircleanerbracket

2.Mountingband8.Inlethose14.Bolt

3.Hexnut9.Hoseclamp15.Mountbracket

4.Shoulderbolt

10.Aircleanerhose16.Hoseclamp

5.Spring

11.Flangenut

6.Serviceindicator

12.Flange-headscrew

Note:Reelmaster5010seriesmachineswithaKubotadieselenginehavevery

similaraircleanerassemblies.Reelmaster5410and5510machinesusethe

sameaircleanerassembly(Figure11).Reelmaster5610machinesuseaslightly

differentaircleanerassembly(Figure12).

RemovingtheAirCleanerAssembly

1.Parkmachineonalevelsurface,lowercuttingunits,stopengine,engage

parkingbrakeandremovekeyfromthekeyswitch.Raiseandsupporthood.

2.Removeaircleanercomponentsasnecessary(Figure11orFigure12).

3.RefertoTractionUnitOperator’sManualforaircleanerserviceand

maintenanceprocedures.

InstallingtheAirCleanerAssembly

IMPORTANT

Anyleaksintheairltersystemwillallowdirtintoengineand

willcauseseriousenginedamage.Ensurethattheallaircleaner

componentsareingoodconditionandareproperlysecuredduring

assembly.

Reelmaster

5410/5510/5610Series

Page3–9

KubotaDieselEngine:ServiceandRepairs

15216SLRevC
