RemovingtheFrontLiftArms

1.Parkthemachineonalevelsurface,lowerthecuttingunits,shutoffthe

engine,settheparkingbrake,andremovethekeyfromthekeyswitch.

2.Removethecuttingunitfromthefrontliftarmtoberemoved.

g215434

Figure313

1.#4liftarm4.Thrustwasher(2each)

2.Liftcylinder5.Cylinderslidepin

3.Retainingring(2each)

3.Disconnecttheliftcylinderfromtheliftarm(item1inFigure313)asfollows:

A.Remove1retainingringandthrustwasherfromthecylinderpinthat

securestheliftcylindertotheliftarm.

B.Pullthecylinderpinfromtheliftcylinderandliftarm.Locateandretrieve

thesecondthrustwasher.

C.Pivottheliftcylinderrodendawayfromtheliftarm.

4.Removethelynchpin(item16Figure312)andslidethepivotyokeassembly

fromtheliftarm.Locateandretrieve2thrustwashers.

5.Removethefastenersthatsecurethebridgeplate(item5or17Figure312)

tothemachine.

6.Slidethefrontliftarmfromtheliftarmpivotshaft(item3inFigure312).

g215435

Figure314

1.#5liftarm2.Liftarmbushing(2each)3.Pivotyokebushing(2

each)

Chassis:ServiceandRepairs

Page8–34

Reelmaster

5410/5510/5610Series

15216SLRevC
