Groundsmaster 4100--D/4110--D Hydraulic SystemPage 4 -- 81
Removal (Fig. 56)
CAUTION
The radiator and oil cooler may be hot. To avoid
possible burns, allow the engine and cooling
systemsto cool before working on the oilcooler.
1. Park machine on a level surface,lowercuttingdeck,
stop engine, apply parking brake and remove key from
the ignition switch. Raise and support hood.
2. Read the General Precautions for Removing and
Installing Hydraulic System Components at the begin-
ning of the Service and Repairs section of this chapter.
3. Remove oil c ooler using Figures 56 as a guide.
Inspection
1. Backflushoilcoolerwithcleaningsolvent.Aftercool-
er is clean, make sure all solvent is drained from the
cooler.
CAUTION
Use eye protection such as goggles when using
compressed air.
2. Dry inside of oil cooler using compressed air in the
opposite direction of the oil flow.
3. Plug both ends ofoilcooler.Cleanexteriorofcooler.
Make sure fins are clear of dirt and debris.
4. The oil cooler should be free of corrosion, cracked
tubes and excessive pitting of tubes.
Installation (Fig. 56)
1. Install oil cooler using Figure 56 as a guide.
2. Fill reservoir with new hydraulic fluid to proper level.
3. Lower and secure hood.
