Toro 30413 Service Manual

Groundsmaster 4100--D/4110--DHydraulic System Page 4 -- 94
Front Wheel Motors
1. Front wheel motor
2. Internal retaining ring
3. Splined brake shaft
4. RH brake assembly
5. Planetary assembly
6. Cap screw (2 used per motor)
7. Flat washer (2 used per motor)
8. O--ring
9. Hex head plug
10. 90
o
hydraulic fitting
11. 90
o
hydraulic fitting
12. O--ring
13. O--ring
14. Hydraulic fitting
15. O--ring
16. O--ring
17. Hydraulic tee fitting
18. O--ring
19. O--ring
20. LH brake assembly
Figure 66
12
13
16
17
14
15
18
20
19
8
7
6
5
4
3
2
1
11
10
9
FRONT
RIGHT
Arrow on side of
motor case points up
1
5
8
11
11
12
12
13
13
13
14
14
15
15
15
16
16
19
Arrow on side of
motor case points up
16
2
3
75 to 85 ft--lb
(101 to 115 N--m)
