Groundsmaster 4100--D/4110--DHydraulic System Page 4 -- 80
Hydraulic Oil Cooler
1. Radiator
2. RH radiator support
3. Top radiator support
4. Knob (2 used)
5. Oil cooler bracket
6. Retaining ring (2 used)
7. Carriage screw (2 used)
8. O--ring
9. 90
o
hydraulic fitting (2 used)
10. O--ring
11. Cap screw (2 used)
12. Lock washer (6 used)
13. Oil cooler
14. Flange nut (2 used)
15. Cap screw (2 used)
16. Oil cooler mount plate (2 used)
17. Cap screw (4 used)
18. LH radiator support
Figure 56
1
2
5
8
7
9
3
10
4
6
15
16
17
18
11
12
13
14
12
FRONT
RIGHT
8
9
10
12 ft--lb
(16 N--m)
