Groundsmaster 4100--D/4110--DHydraulic System Page 4 -- 144
Wing Deck Lift Cylinder
1. Center deck
2. Grease fitting
3. Tapered s tud
4. Spherical bearing
5. Flange nut
6. Retaining ring
7. Wing deck lift cylinder
8. Lock nut
9. Flat washer
10. Lock nut
11. Pilot spacer
12. Cap screw
13. Wing deck (RH shown)
Figure 104
FRONT
RIGHT
6
5
7
8
4
3
2
9
10
1
6
4
11
13
12
2
11
30 to 40 ft--lb
(41to54N--m)
160 to 180 ft--lb
(217 to 244 N--m)
160 to 180 ft--lb
(217 to 244 N--m)
