Groundsmaster 4100--D/4110--DPage 6 -- 2Axles, Planetaries and Brakes
Specifications
Item Specification
Tire pressure (front and rear) 25 to 30 PSI (172 to 207 kPa)
Rear wheel toe--in 0.125 in (3.18 mm)
Planetary gear drive oil SAE 85W--140 wt. gear lube
System gear lube capacity (each wheel) 16 fl. oz. (0.47 liters)
Rear axle lubricant SAE 85W--140 wt. gear lube
System gear lube capacity 80 fl. oz. (2.37 liters)
Rear axle gear box lubricant SAE 85W--140 wt. gear lube
System gear lube capacity 16 fl. oz. (0.47 liters)
Wheel lug nut torque 85 to 100 ft--lb (115 to 135 N--m), front and rear
Steering cylinder castle nut torque 100 to 125 ft--lb (136 to 169 N--m)
Planetary mounting screw torque 75 to 85 ft--lb (101 to 115 N--m)
Brake housing mounting screw torque 75 to 85 ft--lb (101 to 115 N--m)
Front wheel motor mounting screw torque 75 to 85 ft--lb (101 to 115 N--m)
