Toro 30413 Service Manual

Groundsmaster 4100--D/4110--D Page 7 -- 11 Chassis
Disassembly (Fig. 10)
1. Disassemble operator seat as necessary using Fig-
ures 10 and 11 as guides.
Assembly (Fig. 10)
1. Assemble operator seat using Figures 10 and 11 as
guides.
1. Operator seat
2. R--c lamp
3. Screw
4. Manual tube
5. Button head screw
6. Seat belt
7. Flat washer
8. Lock nut
9. Cap screw
10. Lock washer
11. Seat belt mount
Figure 11
2
3
6
8
9
10
1
5
7
4
7
11
Chassis
