Groundsmaster 4100--D/4110--D Cutting DeckPage 8 -- 23
Disassembly (Fig. 22)
1. Park machine on a level surface,lowercuttingdeck,
stop engine, engage parking brake and remove key
from the ignition switch.
2. Disassemble castor forks and wheels using Figure
22 as a guide.
Assembly (Fig. 22)
1. Assemble castor forks and wheels using Figure 22
as a guide.
2. Torque castor wheel lock nut from 60 to 80 ft--lb (81
to 108 N--m).
3. If castor fork was removed, lubricate grease fitting.
4. SeeOperator’sManualforcastorwheeladjustment.
Cutting
Deck
