ADJUSTMENT
3 - 14
<Procedure>
Fig. 3-12
K(4)*: System in which the test pattern is printed only in the black mode, though the four color
developers (Y, M, C, K) are contacted to the transfer belt.
Note:
If the aligning amount is too large, abnormal noise (paper-folding noise) or actual paper folding
may occur during paper feeding. If the aligning amount is too small, on the other hand, a skew,
an image dislocation in feeding direction or a paper exit jam (E010) may occur. Pay attention to
the above and select the appropriate value.
(*1) 1:
3:
55:
56:
57:
58:
59:
60:
98:
Single-sided grid pattern in Black Mode
Double-sided grid pattern in Black Mode
Grid pattern of thick paper 2 in Full Color Mode
Grid pattern of thick paper 3/thick paper 4 in Full Color Mode
Grid pattern of OHP film in Full Color Mode
Single-sided grid pattern of thick paper 2 in Black Mode
Single-sided grid pattern of thick paper 3/thick paper 4 in Black Mode
Single-sided grid pattern of OHP film in Black Mode
Single-sided grid pattern in K(4)
*
Mode
(
Code
) [
START
] (
Sub-code
)[
START
]
[
0
][
5
]
[
Power
]
Current value
displayed
Enter new
value
[
POWER
]
OFF/ON
(
Exit
)
[
Drawer
selection
]
[ ]
+
[
FAX
]
(
Test print
)
[
SET
]
or
[
INTERRUPT
]
Stores in memory
(
Not necessary for LCF
)
*1
