3
© 2008 - 2011 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO2020C/2330C/2820C/2830C/3520C/3530C/4520C
ADJUSTMENT
3 - 31
3.2.2 Density adjustment
The center density and the density variation controlled by density adjustment keys can be adjusted as
follows.
<Adjustment Mode (05)>
* If this setting has been changed, the density levels of the “IMAGE SMOOTHING” or “Photo” in the
black mode may be affected.
<Adjustment Mode (05)>
Make a test copy and compare the image obtained with the current settings; if necessary, make
adjustments according to the following procedure.
Be sure that this adjustment is made after performing P.3-29 "3.2.1 Automatic gamma
adjustment".
<Procedure>
(1) While pressing [0] and [5] simultaneously, turn the power ON.
(2) Key in a code and press the [START] button.
(3) Key in an adjustment value.
(To correct the value once keyed in, press the [CLEAR] button.)
(4) Press the [ENTER] or [INTERRUPT] button to store the value. → The equipment goes back to
the ready state.
(5) Press the [FAX] button and then press the [START] button to make a test copy.
(6) If the desired image quality has not been attained, repeat step (2) to (5).
Color
mode
Original mode
Item to be
adjusted
Remarks
Text/
Photo*
Text*
Printed
Image*
Photo Map
mono
Color
1585 1586 1587 1588 1589 center value The larger the value is, the
darker the image becomes.
Acceptable values:
0 to 255 (Default: 128)
Color
mode
Original mode
Item to be
adjusted
Remarks
Text/
Text
User
custom
Black 503 504 931 Manual density
mode center value
The larger the value is, the darker the image
becomes.
Acceptable values:
0 to 255 (Default: 128)
508 510 937 Manual density
mode dark step
value
The larger the value is, the darker the dark
side becomes.
Acceptable values:
0 to 255 (Default: 20)
505 507 934 Manual density
mode light step
value
The larger the value is, the lighter the light
side becomes.
Acceptable values:
0 to 255 (Default: 20)
514 515 940 Automatic density
mode
The larger the value is, the darker the image
becomes.
Acceptable values:
0 to 255 (Default: 128)
