© 2008 - 2011 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO2020C/2330C/2820C/2830C/3520C/3530C/4520C
ADJUSTMENT
3 - 37
3.2.8 Setting range correction
The values of the background peak/text peak in the range correction at the Black Mode can be
switched to “varied” or “fixed” in the following codes.
If they are fixed, the range correction is performed with standard values.
The values of the background peak affects the reproduction of the background density, and the values
of the text peak affects that of the text density.
<Adjustment Mode (05)>
Make a test copy and compare the image obtained with the current settings; if necessary, make
adjustment.
<Procedure>
The procedure is the same as that of P.3-31 "3.2.2 Density adjustment".
3.2.9 Adjustment of smudged/faint text
The smudge/faint text at a Black Mode can be set at the following codes.
<Adjustment Mode (05)>
Make a test copy and compare the image obtained with the current settings; if necessary, make
adjustment.
Remember the image specifications and life span of the replacing parts may not meet the
standard when the setting value is changed from the default value.
<Procedure>
The procedure is the same as that of P.3-31 "3.2.2 Density adjustment".
Origin
al
mode
Original mode
Item to be adjusted Remarks
Text/
Text
Printed
Photo Map
User
Custo
m
Gray
Scale
Full
color
7767 7768 7769 7770 7771 7777 --- Automatic density mode 0: Background
peak / fixed
1: Background
peak / varied
7772 7773 7774 7775 7776 7778 --- Manual density mode
ACS
black
mode
7667 7668 --- --- --- --- --- Automatic density mode
7669 7670 --- --- --- --- --- Manual density mode
Black 7283 7284 --- --- --- 7236 7295 Automatic density mode
7286 7287 --- --- --- 7237 7296 Manual density mode
Color mode
Original mode
Item to be
adjusted
Remarks
Text/
Text
User
custom
Black 648 649 925 Adjustment of
smudged/ faint text
When the value decreases, the faint
text is improved. When the value
increases, the smudged text is
improved.
Acceptable values: 0 to 4
(Default: 2)
ACS
monochrome
7102 7103 ---
