e-STUDIO2020C/2330C/2820C/2830C/3520C/3530C/4520C © 2008 - 2011 TOSHIBA TEC CORPORATION All rights reserved
ADJUSTMENT
3 - 38
3.2.10 Color Adjustment of Marker
The color of the one touch adjustment “MARKER” can be adjusted so that any marker colors already on
the original can be distinguished.
<Adjustment Mode (05)>
The color may not always be reproduced precisely due to the characteristics of the fluorescent
ink.
<Procedure>
(1) While pressing [0] and [5] simultaneously, turn the power ON.
(2) Key in a code and press the [START] button.
(3) Key in a sub-code and press the [START] button.
(4) Key in an adjustment value.
(To correct a value once keyed in, press the [CLEAR] button.)
(5) Press the [ENTER] or [INTERRUPT] button to store the value. → The equipment goes back to
the ready state.
(6) Turn the power OFF and back ON in the normal mode. Then make a copy in the one touch
adjustment “MARKER” mode.
(7) If the desired image quality has not been attained, repeat step (1) to (6).
Code
Item to be
adjusted
Relation between the adjustment value and the color
(Acceptable values: 0 to 6)
0 to 2 3 (Default) 4 to 6
1769-0 Yellow The smaller the value is,
the more reddish the
color becomes.
Yellow The larger the value is,
the more greenish the
color becomes.
1769-1 Magenta The smaller the value is,
the more bluish the
color becomes.
Magenta The larger the value is,
the more reddish the
color becomes.
1769-2 Cyan The smaller the value is,
the more greenish the
color becomes.
Cyan The larger the value is,
the more bluish the
color becomes.
1769-3 Red The smaller the value is,
the closer to Magenta
the color becomes.
Red The larger the value is,
the more yellowish the
color becomes.
1769-4 Green The smaller the value is,
the more yellowish the
color becomes.
Green The larger the value is,
the closer to Cyan the
color becomes.
1769-5 Blue The smaller the value is,
the closer to Cyan the
color becomes.
Blue The larger the value is,
the closer to Magenta
the color becomes.
