e-STUDIO2020C/2330C/2820C/2830C/3520C/3530C/4520C © 2008 - 2011 TOSHIBA TEC CORPORATION All rights reserved
PREVENTIVE MAINTENANCE (PM)
5 - 18
5.6.4 Automatic duplexing unit
Fig. 5-14
Items to check Cleaning
Lubric
ation/
Coatin
g
Replacement
Operati
on
check
Parts
list
<P-I>
(x 1,000 sheets)
(x 1,000 drive
counts)
D1 Transport roller (upper,
middle and lower)
ARR48-2
48-12
D2 One side of the GCB bushing
to which the shaft is inserted
L
D3 One side of the plastic
bushing to which the shaft is
inserted
W1
D4 Paper guide B 47-4
D1
D1
D1
D4
D2
D3
D2
D3
D3
Front side Rear side
