POWER SUPPLY UNIT
9 - 4
Output voltage by the type of connector
Main switch line
Cover switch line
Connector Destination Voltage
CN402 For the SYS board +5.1 VA, +5.1 VB, +5 VS, +12 VA, +12 VB
CN403 For the IMG board +5.1 VB
CN404 For the LGC, PFP/LCF (via LGC board) +5.1 VB, +12 VB
CN405 For the LGC board +5.1 VB
CN406 For the finisher +5.1 VB
CN407 For the SLG board, RADF +5.1 VB, +12 VB
CN410 For the FIL board +5.1 VB
Connector Destination Voltage
CN405 For the LGC board, PFP/LCF (via LGC
board, high-voltage transformer (via LGC
board)
+5.1 VD, +24 VD1, +24 VD2, +24 VD3
CN406 For the finisher +24 VD4
CN407 For the SLG board, RADF +24 VD
