Programmable Control Module (PCM) Interface
BMTW-SVN01F-EN 93
Programmable Control Module (PCM)
Interface
Description
Programmable control modules (PCMs) allow Tracer Summit to monitor
and control HVAC equipment such as air handlers, chillers, pumps, and
generic loads. You can also use PCMs to add generic analog and binary
inputs and outputs to Tracer Summit.
You can connect PCMs to any isolated Comm3 UCM communication link
on TB2. The link provides a serial communication interface between the
BCU and each PCM in the system. For specific information about the
number of PCMs allowed per BCU and per communication link, refer to
Table 7 on page 46.
104 OFF OFF OFF on OFF on on OFF
105 onOFFOFFonOFFon onOFF
106 OFF on OFF on OFF on on OFF
107ononOFFonOFFononOFF
108 OFF OFF on on OFF on on OFF
109 on OFF on on OFF on on OFF
110 OFF on on on OFF on on OFF
111 on on on on OFF on on OFF
112 OFF OFF OFF OFF on on on OFF
113 on OFF OFF OFF on on on OFF
114 OFF on OFF OFF on on on OFF
115ononOFFOFFonononOFF
116 OFF OFF on OFF on on on OFF
117onOFFonOFFonononOFF
118OFFononOFFonononOFF
119onononOFFonononOFF
120 OFF OFF OFF on on on on OFF
121onOFFOFFononononOFF
122OFFonOFFononononOFF
123 on on OFF on on on on OFF
124OFFOFFonononononOFF
125 on OFF on on on on on OFF
126 OFF on on on on on on OFF
Table 15. LCP Address (Options Select) DIP Switch Settings (Continued)
UCM
Address
DIP-1 DIP-2 DIP-3 DIP-4 DIP-5 DIP-6 DIP-7 DIP-8
