Chapter 5 UCM Wiring and Addressing
96 BMTW-SVN01F-EN
Table 16. PCM Address Settings
UCM
Address
PCM DIP Switch Settings
S2-1 S2-2 S2-3 S2-4 S2-5 S2-6 S2-7 S2-8
1 OFF on on on on on OFF OFF
2 on OFF on on on on OFF OFF
3 OFFOFFononononOFFOFF
4 on on OFF on on on OFF OFF
5 OFF on OFF on on on OFF OFF
6 onOFFOFFon on onOFFOFF
7 OFF OFF OFF on on on OFF OFF
8 onononOFFononOFFOFF
9 OFF on on OFF on on OFF OFF
10 on OFF on OFF on on OFF OFF
11 OFF OFF on OFF on on OFF OFF
12 on on OFF OFF on on OFF OFF
13 OFF on OFF OFF on on OFF OFF
14 on OFF OFF OFF on on OFF OFF
15 OFF OFF OFF OFF on on OFF OFF
16 on on on on OFF on OFF OFF
17 OFFonononOFFonOFFOFF
18 on OFF on on OFF on OFF OFF
19 OFF OFF on on OFF on OFF OFF
20 on on OFF on OFF on OFF OFF
21 OFF on OFF on OFF on OFF OFF
22 on OFF OFF on OFF on OFF OFF
23 OFF OFF OFF on OFF on OFF OFF
24 on on on OFF OFF on OFF OFF
25 OFF on on OFF OFF on OFF OFF
26 on OFF on OFF OFF on OFF OFF
27 OFF OFF on OFF OFF on OFF OFF
28 on on OFF OFF OFF on OFF OFF
29 OFF on OFF OFF OFF on OFF OFF
30 on OFF OFF OFF OFF on OFF OFF
Note:
• DIP switches 7 and 8 must always be off.
• Cycle power off/on after changing settings.
