Chapter 5 UCM Wiring and Addressing
136 BMTW-SVN01F-EN
Table 26. VAV Wireless Receiver Address Settings
UCM Address
VAV Wireless Receiver DIP Switch Settings
DIP 1 DIP 2 DIP 3 DIP 4 DIP 5
1 OFF on on on on
2 on OFF on on on
3OFFOFFononon
4 on on OFF on on
5OFFonOFFonon
6onOFFOFFonon
7 OFF OFF OFF on on
8 onononOFFon
9OFFononOFFon
10 on OFF on OFF on
11 O F F OF F o n O FF o n
12 on on OFF OFF on
13 OFF on OFF OFF on
14 on OFF OFF OFF on
15 OFFOFFOFFOFF on
16 on on on on OFF
17 OFF on on on OFF
18 on OFF on on OFF
19 OFF OFF on on OFF
20 on on OFF on OFF
21 OFF on OFF on OFF
22 on OFF OFF on OFF
23 OFF OFF OFF on OFF
24 on on on OFF OFF
25 OFF on on OFF OFF
26 on OFF on OFF OFF
27 OFF OFF on OFF OFF
28 on on OFF OFF OFF
29 OFF on OFF OFF OFF
30 on OFF OFF OFF OFF
31 OFF OFF OFF OFF OFF
Note:
• DIP switches 6 and 7 are not used. Set them to the on position.
• DIP switch 8 is the Setup/Normal switch. Set it to the on/normal position.
