Chapter 1 Before Installation
4 BMTW-SVN01F-EN
Figure 2. Tracer Summit BCU Component Layout
4 AMP MAX
SET UP TOOL
ONLY
ON OFF
ON
S2
BCU I/O module
cable
Optional BCU I/O
module
Seven-segment
LED display
Option card
slots
High capacity
card slot
Standard capacity
card slot
UCM communication
card slots
Operator
display socket
Mini-monitor
port
