Valtra Versu N174 V

1. Three-pin current socket on the front console (optional)
2. Three-pin current socket on the right-hand side
3. Three-pin current socket on the right-hand side (optional)
4. 25 A
5. 5 A
6. Ground
The direct current is supplied through the current socket for different regulating
elements, implements etc. 5 A is available through the ignition switch and 25 A
direct from the battery. The current supply of the 25 A pin switches off after a
delay when the ignition switch is turned to the
(OFF) position.
3.7.4 Trailer socket
Socket at the rear end
Current from the tractor to the trailer is supplied through the trailer socket.
1
2
3
4
5
6
7
GUID-61A1535A-EAE5-4869-A7E2-359E3574BB25
1. Direction indicator left (yellow)
2. Ignition switch current, max. 10 A (blue)
3. Ground (white)
4. Direction indicator right (green)
5. Parking light right (brown)
6. Parking light left (black)
7. Brake light (red)
3. Operation
- 108 -
