Valtra Versu N174 V

6.6 Flange distance for axles
Front (mm) 1 800
Rear (mm) 1 752
Max rear tyre diameter (mm) 1 885
Min rear rim diameter (inches) 38
Max front tyre diameter (mm) 1 454
Min front rim diameter (inches) 28
Distance between rear mudguards (mm) 960
1
2
3
4
GUID-1835335E-C423-4BCA-B442-6E5A31AD7AD9
1. Distance between the top of the tyre and the mudguard, 60 mm
2. Distance between the side of the tyre and the mudguard, 40 mm
3. Mudguard
4. Narrowest track
6. Technical specifications
- 487 -
