3.19.2.2 Activating rear power take-off
Before you can start the rear power take-off (PTO), you have to activate one of
the rear PTO speed ranges available in your tractor.
IMPORTANT: Do not exceed the maximum PTO speed of the implement defined
by the implement manufacturer.
GUID-0D31E500-E360-4863-B5FE-DB5B63CF763F
1. Speed control knob for rear PTO
• Select the PTO speed with the speed control knob.
The tractor has one of the following PTO speed range alternatives:
• 540/1000
• 540/540E/1000
• 540/1000/1000E
• 540E/1000/GSPTO
• 540E/1000E/GSPTO
IMPORTANT: When using the speed 540E, the shaft speed of 540 rpm is
achieved with an engine speed of approximately 1520 rpm. If the engine
speed is accelerated, the PTO shaft speed can rise up to 800 rpm.
• Activate the ground speed PTO (optional) by turning the speed control knob
to the GSPTO position.
If the system is unable to engage the desired speed range, it will try to engage it
again automatically. Another speed range is first engaged and then a new
attempt is made on the desired speed range. If it still does not engage, you can
restart the engaging operation by first turning the speed selection knob to another
position and then back to the desired position.
The indicator light
on the instrument panel has five different modes to
describe the rear PTO operation.
3. Operation
