3. Press the U-Pilot activation/recording button of the memory slot you are
going to use for more than 2 seconds.
The red indicator light on the button is flashing. Symbol
is in the upper
left corner of the display when a programme is being recorded. An empty U-
Pilot view appears.
GUID-EFDE70BD-932A-4996-AE27-5E70505CBE57
4. Perform the operations in the required order.
The distance between operations is saved as meters but you can change it to
seconds afterwards.
5. When all the operations are recorded, press the U-Pilot activation/recording
button to save the programme.
The symbol
is displayed for a moment. The indicator lights of the U-Pilot
activation/recording buttons are lit. The current hydraulic valve settings are
saved to the auxiliary hydraulics' U-Pilot memory position.
3.20.6.3 Previewing a U-Pilot programme
Before running the U-Pilot programme it is possible to preview it.
1. Press ESC button.
2. Navigate to the menu 2 with the up and down arrow buttons.
3. Press the left arrow button to enter the U-Pilot view.
GUID-18F4B804-649E-4F09-8665-DFF68C1A4F70
4. Select the memory slot you want to preview with the left and right arrow
buttons.
5. Press the down arrow button.
The U-Pilot programme is now available for preview.
3. Operation
- 287 -
