Valtra Versu N174 V

Lowering of the plough.
4WD engaged.
Differential lock engaged.
PS 2
Powershift gear 2.
END
End of the programme.
Example
Activate current socket with U-Pilot programme
Current socket activated.
END
End of the programme.
3.20.6 Using U-Pilot programmes
3.20.6.1 Selecting a U-Pilot programme
1. Press ESC button.
2. Navigate to the menu 2 with the up and down arrow buttons.
3. Press the left arrow button to enter the U-Pilot view.
IMPL1
ABC
1 2
GUID-18F4B804-649E-4F09-8665-DFF68C1A4F70
4. Select the memory slot with the left and right arrow buttons.
5. Press the OK button or the selector for the predefined factory/user settings.
6. Move the selection to the programme selection menu with the left and right
arrow buttons.
7. Press the OK button or the selector for the predefined factory/user settings.
3,5 m
ABC
1 2
IMPL1IMPL1
NEW_1
BACKUP
IMPL2
PLOUGH1
PLOUGH2
IMPL3
GUID-465DB634-6FC6-4E00-8CBB-C5ADFF07AFD3
3. Operation
- 284 -
