4.7.4.19 Changing the front PTO housing oil and washing the oil filter
Change the oil of the front power take-off (PTO) housing and wash the oil filter
periodically.
GUID-3FCD3A79-9507-46E9-B88E-689452970CBB
1. End plate
2. Lock ring
3. O-ring
4. Filter
5. Oil level hole
6. Breather
7. Front PTO housing fastening screw
1. Open the oil level hole plug.
2. Drain the oil by opening the two front PTO housing fastening screws at the
bottom of the housing.
3. Release the filter by loosening the lock ring and the end plate.
4. Clean the filter with diesel.
5. Dry the filter with compressed air.
6. Attach the filter and the parts in the contrary order.
Check that the O-ring fits the groove of the end plate.
7. Tighten the two front PTO housing fastening screws at the bottom of the
housing.
