Valtra Versu N174 V

6.10.5.4 Lower link end distance from rear power take-off shaft
The length of the lower links (mm) Width of implement attachment (T measure, mm)
Cat. 2 Cat. 3
960 706 693
2
1
GUID-704E95B6-4DD3-4925-A46A-1C1C8BA6394E
1. 229 mm
2. T measure
6.10.5.5 Proportional ground speed power take-off
Model
Power take-off (PTO) axle revolutions per one rear
wheel revolution
40 km/h 40.81
50 km/h 40.96
6.10.6 Front power take-off
Oil type
Oil volume (litres)
Shell Spirax S4 ATF HDX 2.8
Maximum input torque (Nm) 759
Nominal input torque (Nm) 692
Maximum input torque with pivoting front linkage
(extra equipment) (Nm)
732
Nominal input torque with pivoting front linkage (extra
equipment) (Nm)
549
6.10.6.1 Front power take-off ratio
Front power take-off (PTO) ratio
1 000 rpm at engine speed 2 000 rpm
6.10.6.2 Front power take-off shafts
Splines
Standard Shaft diameter (mm)
6 ISO 500 35
6. Technical specifications
- 495 -
