4. Move the navigation box to the ASR position with the arrow buttons.
A short press moves the box in the selected direction one field at a time. A
long press moves the box in the selected direction continuously.
SET
1
2
3
4
4
1600 RPM 2000 RPM
F/R
F
R
C D
AUTO
AUTO 2
GUID-6E2A5868-6079-4A42-8202-AE7DCB0AA7F8
1. Setting the ASR
5. Select the desired status of the ASR with the up or down arrow button.
• When the box is checked the ASR is activated.
• When the box is not checked the ASR is deactivated.
6. Change the slip regulation value with the up or down arrow button.
The value can be chosen between 1 and 5. Value 1 allows for lowest slipping
percentage. Value 5 allows for highest slipping percentage.
The value is automatically saved when you deactivate the selected field by
moving the navigation box to another parameter or by pressing the ESC
button.
With a short press of the ESC button you can return to the menu 2. A long press
of the ESC button returns to the previously active drive display.
3.8.22 QuickSteer
3.8.22.1 QuickSteer
QuickSteer is a steering system controlled by an electrohydraulic steering valve.
QuickSteer means adjustable steering ratio which gives a great advantage
whenever the driver needs to steer a lot, for example when driving in a small yard
or when doing front loader work. QuickSteer is optional equipment.
QuickSteer has five manually set steering speeds for both forward and reverse
driving. The steering speed setting is dependent on the driving speed so that the
difference between different steering speeds is more substantial at low driving
speeds, whereas at the speed of 20 km/h the steering speed is fixed.
NOTE: When driving on a slippery road with QuickSteer activated, the steering
speed decreases if the tractor is in a four-wheel slide and you try to increase the
speed. Therefore, it is recommended to use the slowest QuickSteer setting when
driving on slippery surfaces.
3. Operation
- 153 -
