Valtra Versu N174 V

6.5.1 Wheel nut tightening torques
Wheel nut Tightening torque (Nm)
Front 450
Rear 450
Rim - wheel disc (front and rear) 210
6.5.2 Wheel stud dimensions
Front axle Rear axle
Stud dimension M20x1.5 M20x1.5
Stud length (mm) 44 65
Number of studs per side 8 8
Rear disc
1
2
3
GUID-21661BAE-D298-4226-ABD8-9E09755404CC
1. Rear disc stud hole diameter 24 mm
2. Rear tread clearance 275 mm
3. Rear disc center hole diameter 221 mm
Front disc
1
2
3
GUID-F4062928-D1FC-4F46-8636-74C879F1F628
1. Front disc stud hole diameter 23 mm
2. Front tread clearance 275 mm
3. Front disc center hole diameter 220.6 mm
6. Technical specifications
