Injection system
Common rail injection High-pressure pump with electronic injection control
6.8.3 Selective catalytic reduction system
System type
Bosch DENOXTRONIC 2.2+
Fluid type DIN70070/ISO22241-certified AdBlue/DEF
Standard tank capacity 45 liters
Forest tank capacity 25 liters
6.8.4 Air cleaner
Air cleaner Two-stage, dry element, with blockage indicator
Pre-cleaner system Ejector
6.8.5 Cooling system
Pump Centrifugal
Radiator Pressurised with expansion tank regulated by
pressure cap
Thermostat One thermostat at 83°C
Fan The belt-driven fan is controlled by the engine's
control module for precise fan speed modulation
Coolant Engine coolant mixed with water. ASTM D6210 Type
I-FF, ASTM D3306.
In first fill, OAT-coolant (Organic Acid Technology)
used, not recommended to mix with old type of
coolants.
Coolant, Valtra grade
Valtra Coolant
Coolant volume 18 liters
6.9 Electrical system
Ground
Negative
Voltage 12 V
Battery 174 Ah
Alternator 150 A
Starter motor 4.3 kW
Suction air preheater (engine induction air) 2.1 kW
Fuses
Cab electric centre 36 fuses
The nominal current rating of the fuses is 5–25 A.
Roof electric centre 25 fuses
The nominal current rating of the fuses is 10–30 A.
Main fuse centre 4 fuses
The nominal current rating of the fuses is 25–250 A.
Engine electric centre 12 fuses
The nominal current rating of the fuses is 3–25A.
Electric preheating of engine induction air 250 A
Cab power supply 125 A
6. Technical specifications
- 492 -
