1)
Placed behind the light panel.
4.8.6.8 Fuses and relays in the Skyview equipment roof electric centre
The fuses and relays in the Skyview equipment roof electric centre are listed in
the following tables.
The fuse diagram is on the reverse side of the electric centre cover. There is
space for spare fuses. The roof electric centre contains 27 fuses and the nominal
current rating of these fuses is 5-30 A.
GUID-0549EC70-D0CF-4C46-ABEC-DC5F4C1C35AA
1. Skyview equipment roof electric centre
4. Maintenance
- 446 -
