Valtra Versu N174 V User Manual

Lifting force and range
with Ø100 mm cylinder
First fastening point Second fastening point Third fastening point
Lifting range (mm) 862 783 721
Max lifting force (kN)
1)
68.5 74 78
In whole range (kN)
1)
62 69 76
1)
Calculated with rear tire radius R=875, for example tires 520/85R38
6.14.5 Front linkage
Lifting force 47 kN
Number of lifting cylinders 2
Diameter of the lifting cylinders 90 mm
Lifting range at the end of the lifting links 840 mm
Quick coupling hooks Category 3/2
6.14.6 Towing devices
6.14.6.1 Pick-up hitch
NOTE: The loadings are applicable to all tires.
Maximum permissible vertical loading
3000 kg
1)
Pick-up hitch height from the ground (lowest position
and tyre radius R=925 mm)
216mm
D-value
2)
81.8 kN
Drawbar eye standard ISO 5692-1 or ISO 20019
1)
The maximum axle loading must not be exceeded
2)
Mathematically established horizontal force
6.14.6.2 Euro pick-up hitch
NOTE: The loadings are applicable to all tires.
Hitch or drawbar
Replaceable
Maximum permissible vertical loading for the tow
hook and K80 ball hitch
3000 kg
1)
Pick-up hitch height from the ground (lowest position
and tyre radius R=925 mm)
208 mm
D-value
2)
• Hook: 87.7 kN
• K80 ball: 84.8 kN
• Drawbar: 62.3 kN
Drawbar pin diameter
32 mm
Drawbar eye standard for towing hook ISO 5692-1 or ISO 20019
Drawbar eye standard for drawbar ISO 5692-1, ISO 5692-2, ISO 8755, ISO 1102
Drawbar eye standard for 80 mm ball hitch ISO 24347
1)
Maximum loading is applicable to all tires
2)
Mathematically established horizontal force
