Valtra Versu N174 V

2.6.2 Driving controls
CONTROL
STOP
1
1
2
2
OFF
ON
OFF
AUTO
CONTROL
1
2
3
4
5
6
7
9
10
11
12
13
14
15
16
17
8
18
19
20
21
22
23
GUID-947389D4-6A83-4E0D-908F-359AA7148F96
1. Emergency brake button
2. Switch for four-wheel drive (4WD)
3. Switch for differential lock
4. QuickSteer control knob (optional)
5. QuickSteer activation button (optional)
6. Auto-Guide steering valve on/off button (optional)
7. Auto-Guide receiver on/off button (optional)
8. Front axle suspension switch (optional)
9. Control stop switch (optional)
10. PowerShift limit push button
11. Gear lever
12. Cruise control speed adjustment wheel
13. Push button for EcoPower (optional)
14. Push button for shifting automatics
15. Activation / recording button 1 for U-Pilot
16. Activation / recording button 2 for U-Pilot
17. U-pilot on/off button
18. Driving speed cruise control off button
19. Driving speed cruise control memory button 2
20. Driving speed cruise control memory button 1
2. Instruments and controls
- 48 -
