GUID-C4DD8714-5A7C-4E77-9A47-3A4181B6C6D0
1. Lifting push button
2. Lowering push button
• To lift the linkage, press the lifting push button.
The longer the lift button is pressed the faster the linkage lifts.
• To lower the linkage, press the lowering push button.
The longer the lower button is pressed the faster the linkage lowers.
NOTE: The linkage has to be activated again every time the lifting/lowering
switch or the lifting/lowering push buttons have been used, if necessary.
3.13.10 Setting the lowering speed
The needed lowering speed depends on the type of implement used. Use low
lowering speed with heavy and sensitive implements. The setting does not affect
the lifting speed.
The lowering speed is independent of the load.
GUID-0FBC4240-E5B4-4642-9EE5-F88C68589A74
1. Lowering speed selector
• To increase the lowering speed, turn the knob clockwise.
Nine different levels are available.
• To decrease the lowering speed, turn the knob anti-clockwise.
3. Operation
- 215 -
