• To start the rear PTO with the rear PTO on/off push button (optional) on the
mudguard, press the button continuously for at least 3 seconds.
The PTO starting begins after 0.5 seconds. If the pressing is interrupted
during these 3 seconds, the PTO stops.
GUID-CAAA1849-6895-4A59-BBC2-84694B1B18D4
1. Rear PTO on/off push button
3.19.2.4 Stopping rear power take-off temporarily
You can stop the rear power take-off (PTO) temporarily in the following ways:
• By using the switch for rear PTO.
• By using the speed control knob for rear PTO.
• By using the rear PTO on/off push button (optional) on the rear mudguard.
WARNING: When you do not need the PTO, keep the PTO switch in
the N position.
WARNING: Use the PTO speed control knob for the actual
disengagement and engagement of the PTO. For example, when
leaving the cab, turn the knob to the N position, except when using the
PTO on/off push button on the mudguard (optional).
3. Operation
- 270 -
