Valtra Versu N174 V

1. Hydraulic pick-up hitch
2. K80 ball hitch with steering balls (optional)
3. Trailer hitch
4. K80 ball hitch (optional)
5. Drawbar (optional)
When the trailer hitch or drawbar is not in use, it can be fastened to its bracket.
1
GUID-3BE0BDED-4092-4A55-AA3A-9C70F7E4A40A
1. Bracket
3.24.4 Using the pickup hitch
3.24.4.1 Unlatching the pick-up hitch
WARNING: Never unlatch the pick-up hitch when driving.
1
2
GUID-BFBBA849-E397-4C34-A781-9C11E344292D
1. Lifting/lowering switch
2. Trailer hitch release lever
1. Press the symbol side of the lifting/lowering switch to fully raise the linkage.
2. Pull the hitch latch lever to unlatch the hitch.
Keep the lever pulled.
3. Press the lifting/lowering switch side opposite to the symbol to lower the
linkage.
3. Operation
- 307 -
