Valtra Versu N174 V

3.17.2.2 Adjusting the turning ratio
The turning ratio controller controls how much the Valtra LHLink turns in relation
to the front wheels.
CAUTION: When the steering wheel is not in the centre position and
the turning ratio controller knob is adjusted, the LHLink may turn
unexpectedly.
1
GUID-9CD956DF-F5E1-4888-83DC-BB377A1B4318
1. Turning ratio controller knob
• To decrease the turning of the Valtra LHLink, rotate the controller knob to
leftwards.
The Valtra LHLink turns less in relation to the front wheels.
• To turn the Valtra LHLink in relation with the front wheel, rotate the controller
knob to middle position.
The Valtra LHLink turns in relation to the front wheels.
• To increase the turning of the Valtra LHLink, rotate the controller knob to
rightwards.
The Valtra LHLink turns more in relation to the front wheels.
3. Operation
- 255 -
