GUID-E79F0D02-F528-412A-9AB3-40219C6B133B
1. Hydraulic oil fill cap
IMPORTANT: Clean the filler cap before filling up with oil. Make sure
there are no impurities in the oil before filling up.
• Close the steps.
Fasten the steps with the two fastening screws.
5. Check the leakage oil reservoir for the quick couplings and empty it
occasionally.
GUID-4656168A-4AEC-4CBE-9B4D-27DF3F537D6B
1. Leakage oil reservoir
4. Maintenance
- 353 -
