Valtra Versu N174 V

2. Grease the top link.
1
2
3
4
5
5
5
5
GUID-FC401A5E-A002-471B-9ABA-BF41593EE486
1. Top link
2. Top link with ball hitch
3. Hydraulic top link
4. Hydraulic top link with ball hitch
5. Grease nipple
There are two grease nipples in the top link.
3. Grease the lifting cylinder pins.
1
2
GUID-9C04FF82-32EA-4422-A4AE-05851D314510
1. Upper pin grease nipple
2. Lower pin grease nipple
There are two grease nipples in the lifting cylinder.
4. Maintenance
- 355 -
