Valtra Versu N174 V

2. Remove the latch of the air intake pipe.
2
1
3
GUID-C8F333DB-6F82-4DA2-836F-BDFF0F52B23B
1. Latch
2. Fastening screw
3. Air intake pipe support
Unscrew the fastening screw and remove the latch.
3. Remove the clamp of the air intake pipe.
1
2
3
GUID-7442B98F-5893-4D86-AA4C-78931437B034
1. Clamp screw
2. Clamp
3. Rubber pin
4. Remove the air intake pipe.
Pull the rubber pin off the fitting.
4. Maintenance
- 387 -
