Vermeer Navigator D20x22 II Series User Manual

D20x22 Series II Navigator HDD Machine Controls 20-11
ENGINE MONITORS
(1) High Coolant Temperature Light (red)
Comes on if coolant becomes too hot
(2) Low Oil Pressure Light (red)
Comes on when oil pressure is low
(3) Insufficient Voltage Light (yellow)
Comes on when voltage not sufficient
(4) Warning Light (yellow)
Comes on when engine shuts down due to low engine oil pressure or
high coolant temperature
(5) Display
Shows engine hours, engine RPM (6) and fuel level (7)
3
2
1
7
6
4
5
