20-24 Machine Controls D20x22 Series II Navigator HDD
FUSES
Fuses protect electrical circuits and are located in compartment under left armrest. When replacing them, use
fuses with the correct rating to prevent damaging electrical system.
Tier 3/Stage IIIA Engine Tier 4 Interim/Stage IIIB Engine
Throttle Up
F1-15A
Lights
Front
Stakedown
F1-15A
Lights
F2-15A
Empty
F2-15A
Empty
Throttle
Down
F3-15A
Display
F3-15A
Display
F4-15A
Throttle Relay
F4-15A
Strike Alert
F5-15A
Joysticks
F5-15A
Joysticks
F6-15A
Empty
F6-15A
Remote Lockout
F7-20A
Controller
F7-20A
Controller
F8-15A
Limit Switch
F8-15A
Limit Switch
F9-15A
Remote Lockout
F9-15A
Shutdown
15A -
Auxiliary
Power
F10-15A
Stakedowns
15A -
Auxiliary
Power
F10-15A
Stakedowns
