D20x22 Series II Navigator HDD Overview 30-3
REMOTE TRANSMITTER
The remote transmitter (1) clips onto the user’s belt and has a
range of 3300 ft (1 km). The range is dependent on usage in urban
or rural areas, and on weather and environmental conditions.
The remote transmitter user can select either RUN or LOCKOUT
mode, indicated by lights and buzzer.
A battery charger (2) for the transmitter location is located under
the left armrest; transmitter storage is behind right operator
console. Refer to “Recharge Battery,” page 30-12.
A steady buzzer will sound at the machine if radio communication
is not established within 10 seconds of entering Drill mode and
machine is not locked out. Refer to “Remote Lockout Tests,” page
30-6. If machine is locked out, the audible lockout signal will
sound and red lockout light (3) will be on.
1
2
3
