2. Press the {DOOR OPEN} button.
3. Hang-up to return to idle.
Conditions
1. The Summit has two External Control Contacts, one each located on the
Miscellaneous connector of the KSU and EKSU.
2. The Door Open feature dial code is based on the assigned External Contact as below:
 External Contact 1 = ―#*1‖
 External Contact 2 = ―#*2‖
3. The contacts are rated at 1 amp, 24 VDC.
4. A station will receive error tone if not allowed access to the Door Open feature (PGM
113-Button 24-2)
Programming
Keyset Admin.
YSTEM
External Contact Control (PGM 168)
Door Open Timer (PGM 181-Button 5)
STATION
Door Open (PGM 113-Button 24-2)
Web Admin.
STATION
Common Attributes Door Open
SYSTEM DATA
External Control Contacts
System Timers Door Open Timer
Related Features
 LBC (Loud Bell Control)
Hardware
 External Control Contact connected to a door-lock release mechanism.
