2.76.3 SMDR Call Records
Description
SMDR (Station Message Detail Recording) provides detailed information on incoming and
outgoing calls. Assignable options in the system database permit recording of all external calls, all
external outgoing calls or toll calls, calls that exceed a fixed duration and intercom calls. Call
records are output either upon completion of the call (real-time) or in response to a request from
the System Attendant. SMDR may be sent periodically via e-mail to a defined e-mail address.
The SMDR record output for external calls is as shown in the figure below. There are two flexible
fields, Field I and Field II. Each Field is defined to show Ring duration, CLI (Caller Id) or CPN
(Called Party Number).
NO
STA
CO
TIME
START
DIAL/CLI/CPN
NUM-1
COST
ACCOUNT
CODE
DIAL/CLI/CPN
NUM II
DC
XXXX
SSSS
BBB
DD:DD
FF/FF/FF
EE:EE
HCCCCCCCCCC
CCCCCCCC
sssss
Aaaaaaaa
aaaa
Hccccccccccc
ccccccc
The various fields or items for a Call Record are:
NO
SMDR record number, optional output, (PGM 177-Button 23)
STA
3 or 4 digit station number
CO
2 or 3 digit CO Line number
Time
Call duration in minutes and seconds
Start
Date and time call was placed/received
NUM I
Flex Field I, for outgoing call displays dialed number, for incoming call
displays Ring duration, CLI or CPN (PGM 177-Button 20)
Cost
Cost of Call
Account Code
Account code entered for call
NUM II
Flex Field II for incoming call, displays Ring duration, CLI or CPN or
blank, (PGM 177-Button 23)
DC
Disconnect Cause, optional output (PGM 177-Button 24-5), with value:
01~7F: Follow cause value of Q.931 specification,
81: Disconnected, toll restricted
84/85: Disconnected, disconnect supervision
