Vertical Summit80 & Summit800
Feature Description and Operation Manual Issue 1.2
227
The SMDR record output for internal calls is as shown in the figure and explained in the chart
below.
---- Site Name : --------------------------------------------------------------------------------------
1) Station 100 called station 101 and station 101 answered.
2) In a conference, station 100 was a conference master, station 101
was a conference member.
Station 105 sent an internal SMS to station 103.
Station 110 was the member of conference room 1.
Station 120 paged station 123.
Operation
System
For real-time SMDR, records are output after completion of the call as shown in the figures
above
System Attendant
To print SMDR records
1. Press the [TRANS/PGM] button.
2. Dial ―0111‖, the SMDR print code.
3. Enter the desired station range.
4. Press the [HOLD/SAVE] button.
To delete stored records
1. Press the [TRANS/PGM] button.
2. Dial ―0112‖, the SMDR delete code.
3. Enter the desired station range.
4. Press the [HOLD/SAVE] button.
To abort SMDR printing
1. Press the [TRANS/PGM] button.
2. Dial ―0114‖, the SMDR abort code.
3. Press the [HOLD/SAVE] button.
